If there is a network problem, DVR can wait for the specified time
you set here to send out the POS information. Once the network
time is out, DVR only send out current valid POS information
when then network resumes normal.
It is to set the POS information displayed time on the video. If you
set 5 seconds, then the POS information appears after 5 seconds
display.
Click it to go to Figure 5-130. Select a channel you want to
overlay POS information and then click Save button
Note
The POS device name shall be unique.
POS device name max supports 63-digit.
Click Setup button after the connection mode, the interface is shown as in Figure 5-129.
Here you can set source IP (POS device IP address) and source IP (DVR IP address).
Figure 5-129
In Figure 5-128, click Channel button at the bottom of the interface, select a channel you want to overlay
POS information and then click Save button. See Figure 5-130.
Figure 5-130
5.5.5.7 Voice
The audio function is to manage audio files and set schedule play function. It is to realize audio broadcast
activation function.
5.5.5.7.1 File List
From main menu->Setup->System->Voice->File list, here you can add audio file, or delete audio file. See
Figure 5-131.
