Application Guide | iC2-Micro Frequency Converters
Use this parameter to select the ramp type, depending on requirements for acceleration and deceleration. A linear ramp provides
constant acceleration during ramping. Sine Ramp and Sine 2 Ramp provide non-linear acceleration.
Default value: 0 [Linear] Parameter type: Selection
Parameter
number:
340 Unit: –
Data type: enum Access type: Read/Write
The following are the selections for the parameter.
Selection number Selection name Selection description
0 Linear
1 Sine Ramp
2 Sine 2 Ramp Only be used with speed control mode) S-ramp based on the
values set in P 5.5.4.2 Ramp 1 Accel. Time and P 5.5.4.3 Ramp 1
Decel. Time.
P 5.5.4.2 Ramp 1 Accel. Time
Use this parameter to enter acceleration time. The values range from 0 Hz to the motor frequency defined in P 4.2.2.4 Nominal
Frequency. Select a ramp up time such that the output current does not exceed the current limit in P 2.7.1 Output Current Limit % during
ramping.
Default value: Size Related Parameter type: Range (0.01–3600.00)
Parameter
number:
341 Unit: s
Data type: uint32 Access type: Read/Write
P 5.5.4.3 Ramp 1 Decel. Time
Use this parameter to enter the deceleration time. The values range from the motor frequency defined in P 4.2.2.4 Nominal Frequency to
0 Hz. Select a ramp down time such that no overvoltage occurs in the inverter due to regenerative operation of the motor, and such that
the generated current does not exceed the current limit set in P 2.7.1 Output Current Limit %.
Default value: Size Related Parameter type: Range (0.01–3600.00)
Parameter
number:
342 Unit: s
Data type: uint32 Access type: Read/Write
P 5.5.4.8 Ramp 2 Type Selector
Use this parameter to select the ramp type, depending on requirements for acceleration and deceleration. A linear ramp provides
constant acceleration during ramping. Sine Ramp and Sine 2 Ramp provide non-linear acceleration.
Default value: 0 [Linear] Parameter type: Selection
Danfoss A/S © 2024.03 AB413939445838en-000301 / 130R1254 | 163
