Application Guide | iC2-Micro Frequency Converters
Selection number Selection name
8 Main Actual Value [%]
9 Custom Readout
10 Power [kW]
11 Power [hp]
12 Motor Voltage
13 Frequency
14 Motor Current
15 Frequency [%]
16 Torque [Nm]
17 Motor Thermal
18 DC Link Voltage
19 Heat Sink Temperature
20 Inverter Thermal
22 External Reference
23 Feedback [Unit]
24 Digital Input 13, 14, 15, 17, 18
25 Terminal 33 Switch Setting
26 Analog Input 33
27 Terminal 34 Switch Setting
28 Analog Input 34
29 Analog Output 31 [mA]
30 Relay Output
33 Fault Word
34 Warning Word
35 External Status Word
39 Fault Word 2
40 Warning Word 2
43 Speed [RPM]
44 Digital Output
54 External Status Word 2
55 Fault Word 3
56 Warning Word 3
81 User Define 8
