Danfoss VLT AQUA Drive FC 202 Design Guide

Description Position
Possible choices
1)
Line power
option
21 X: No line power option
1: Line power disconnect
3: Line power disconnect and fuse
5: Line power disconnect, fuse
and load sharing
7: Fuse
8: Line power disconnect and load
sharing
A: Fuse and load sharing
D: Load sharing
Adaptation 22 X: Standard cable entries
O: European metric thread in
cable entries
S: Imperial cable entries
Adaptation 23 X: No adaptation
Software
release
24-
27
SXXX: Latest release – standard
software
Software
language
28 X: Not used
Table 6.1 Ordering Type Code
1) Some of the available choices depend on the enclosure size.
2) Only available for adjustable frequency drives ≥ 75 kW (100 hp).
3) Only available for adjustable frequency drives
≥ 355 kW (475 hp).
Description Position Possible choices
A options 29-
30
AX: No A option
A0: MCA 101 PROFIBUS DP V1
(standard)
A4: MCA 104 DeviceNet
(standard)
AN: MCA 121 Ethernet IP
AL: MCA 120 ProNet
AQ: MCA 122 Modbus TCP
B options 31-
32
BX: No option
BY: MCO 101 extended cascade
control
BK: MCB 101 general purpose
I/O option
BP: MCB 105 relay option
B0: MCB 109 I/O option with RTC
backup
B2: MCB 112 PTC thermistor card
B4: MCB 114 VLT sensor input
C0 options 33-
34
CX: No option
C1 options 35 X: No option
R: MCB 113 Ext. relay card
5: MCO 102 Advanced cascade
control
Description Position Possible choices
C option
software
36-
37
XX: Standard controller
D options 38-
39
DX: No option
D0: Extended 24 V DC backup
Table 6.2 Ordering Type Code, Options
NOTICE!
For power sizes over 90 kW (125 hp), see the VLT
®
AQUA
Drive FC 202 110–1400 kW Design Guide.
Type code and Selection
VLT
®
AQUA Drive FC 202
122 Danfoss A/S © 09/2014 All rights reserved. MG20N622
