7.1 Electrical Data
7.1.1 Line Power Supply 1x200–240 V AC
Type designation P1K1 P1K5 P2K2 P3K0 P3K7 P5K5 P7K5 P15K P22K
Typical shaft output [kW] 1.1 1.5 2.2 3.0 3.7 5.5 7.5 15 22
Typical shaft output at 240 V [hp] 1.5 2.0 2.9 4.0 4.9 7.5 10 20 30
Protection rating IP20/Chassis A3 - - - - - - - -
Protection rating IP21/Type 1 - B1 B1 B1 B1 B1 B2 C1 C2
Protection rating IP55/Type 12 A5 B1 B1 B1 B1 B1 B2 C1 C2
Protection rating IP66/NEMA 4X A5 B1 B1 B1 B1 B1 B2 C1 C2
Output current
Continuous (3x200–240 V) [A] 6.6 7.5 10.6 12.5 16.7 24.2 30.8 59.4 88
Intermittent (3x200–240 V) [A] 7.3 8.3 11.7 13.8 18.4 26.6 33.4 65.3 96.8
Continuous kVA at 208 V [kVA] 2.4 2.7 3.8 4.5 6.0 8.7 11.1 21.4 31.7
Maximum input current
Continuous (1x200–240 V) [A] 12.5 15 20.5 24 32 46 59 111 172
Intermittent (1x200–240 V) [A] 13.8 16.5 22.6 26.4 35.2 50.6 64.9 122.1 189.2
Maximum pre-fuses [A] 20 30 40 40 60 80 100 150 200
Additional specications
Maximum cable cross-section (line power, motor,
brake)
[mm
2
] ([AWG])
0.2-4 (4-10) 10 (7) 35 (2) 50 (1/0) 95 (4/0)
Maximum cable cross-section
2)
for line power with
disconnect switch
[mm2] ([AWG])
16 (6) 16 (6) 16 (6) 16 (6) 16 (6) 16 (6) 25 (3) 50 (1/0)
2 x 50 (2
x 1/0)
9)
10)
Maximum cable cross-section
2)
for line power
without disconnect switch
[mm2] ([AWG])
16 (6) 16 (6) 16 (6) 16 (6) 16 (6) 16 (6) 25 (3) 50 (1/0) 95 (4/0)
Cable insulation temperature rating [°C (°F)]
75
(167)
75
(167)
75
(167)
75
(167)
75
(167)
75 (167) 75 (167) 75 (167) 75 (167)
Estimated power loss
3)
at rated maximum load [W]
4)
44 30 44 60 74 110 150 300 440
Eciency
5)
0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98
Table 7.1 Line Power Supply 1x200–240 V AC, Normal Overload 110% for 1 Minute, P1K1–P22K
