Danfoss VLT AQUA Drive FC 202 Design Guide

6.2.7 Harmonic Filters
Harmonic lters are used to reduce line harmonics.
•
AHF 010: 10% current distortion
•
AHF 005: 5% current distortion
Cooling and ventilation
IP20: Cooled by natural convection or with built-in fans.
IP00: Additional forced cooling is required. Secure sucient airow through the lter during installation to prevent
overheating of the lter. Airow of minimum 2 m/s is required through the lter.
Power and current
ratings
1)
Typical
motor
Filter current rating
Ordering number AHF 005 Ordering number AHF 010
50 Hz
[kW (hp)] [A] [kW (hp)] [A] IP00 IP20 IP00 IP20
0.37–4.0 (5–
5.4)
1.2-9 3 (4) 10 130B1392 130B1229 130B1262 130B1027
5.5–7.5
(7.5–10)
14.4 7.5 (10) 14 130B1393 130B1231 130B1263 130B1058
11.0 (15) 22 11 (15) 22 130B1394 130B1232 130B1268 130B1059
15.0 (20) 29 15 (20) 29 130B1395 130B1233 130B1270 130B1089
18.0 (24) 34 18.5 (25) 34 130B1396 130B1238 130B1273 130B1094
22.0 (30) 40 22 (30) 40 130B1397 130B1239 130B1274 130B1111
30.0 (40) 55 30 (40) 55 130B1398 130B1240 130B1275 130B1176
37.0 (50) 66 37 (50) 66 130B1399 130B1241 130B1281 130B1180
45.0 (60) 82 45 (60) 82 130B1442 130B1247 130B1291 130B1201
55.0 (75) 96 55 (75) 96 130B1443 130B1248 130B1292 130B1204
75.0 (100) 133 75 (100) 133 130B1444 130B1249 130B1293 130B1207
90.0 (125) 171 90 (125) 171 130B1445 130B1250 130B1294 130B1213
Table 6.18 Harmonic Filters for 380–415 V, 50 Hz
Power and current
ratings
1)
Typical
motor
Filter current rating
Ordering number AHF 005 Ordering number AHF 010
60 Hz
[kW (hp)] [A] [kW (hp)] [A] IP00 IP20 IP00 IP20
0.37–4.0 (5–
5.4)
1.2-9 3 (4) 10
130B3095 130B2857
130B2874 130B2262
5.5–7.5
(7.5–10)
14.4 7.5 (10) 14
130B3096 130B2858
130B2875 130B2265
11.0 (15) 22 11 (15) 22 130B3097 130B2859 130B2876 130B2268
15.0 (20) 29 15 (20) 29 130B3098 130B2860 130B2877 130B2294
18.0 (24) 34 18.5 (25) 34 130B3099 130B2861 130B3000 130B2297
22.0 (30) 40 22 (30) 40 130B3124 130B2862 130B3083 130B2303
30.0 (40) 55 30 (40) 55 130B3125 130B2863 130B3084 130B2445
37.0 (50) 66 37 (50) 66 130B3026 130B2864 130B3085 130B2459
45.0 (60) 82 45 (60) 82 130B3127 130B2865 130B3086 130B2488
55.0 (75) 96 55 (75) 96 130B3128 130B2866 130B3087 130B2489
75.0 (100) 133 75 (100) 133 130B3129 130B2867 130B3088 130B2498
90.0 (125) 171 90 (125) 171 130B3130 130B2868 130B3089 130B2499
Table 6.19 Harmonic Filters for 380–415 V, 60 Hz
Type code and Selection Design Guide
MG20N622 Danfoss A/S © 09/2014 All rights reserved. 141
