Power and current
ratings
1)
Typical
motor
Filter current rating
Ordering number AHF 005 Ordering number AHF 010
60 Hz
[kW (hp)] [A] [kW (hp)] [A] IP00 IP20 IP00 IP20
0.37–4.0 (5–
5.4)
1–7.4 3 (4) 10 130B1787 130B1752 130B1770 130B1482
5.5–7.5
(7.5–10)
9.9–13 7.5 (10) 14 130B1788 130B1753 130B1771 130B1483
11.0 (15) 19 11 (15) 19 130B1789 130B1754 130B1772 130B1484
15.0 (20) 25 15 (20) 25 130B1790 130B1755 130B1773 130B1485
18.0 (24) 31 18.5 (25) 31 130B1791 130B1756 130B1774 130B1486
22.0 (30) 36 22 (30) 36 130B1792 130B1757 130B1775 130B1487
30.0 (40) 47 30 (40) 48 130B1793 130B1758 130B1776 130B1488
37.0 (50) 59 37 (50) 60 130B1794 130B1759 130B1777 130B1491
45.0 (60) 73 45 (60) 73 130B1795 130B1760 130B1778 130B1492
55.0 (75) 95 55 (75) 95 130B1796 130B1761 130B1779 130B1493
75.0 (100) 118 75 (100) 118 130B1797 130B1762 130B1780 130B1494
90 (125) 154 90 (125) 154 130B1798 130B1763 130B1781 130B1495
Table 6.20 Harmonic Filters for 440–480 V, 60 Hz
1) Adjustable frequency drive power and current ratings according to actual operating conditions
Power and current
ratings
1)
Typical
motor
Filter current rating
Ordering number AHF 005 Ordering number AHF 010
60 Hz
[kW (hp)] [A] [kW (hp)] [A] IP00 IP20 IP00 IP20
11.0 (15) 15 10 (13) 15 130B5261 130B5246 130B5229 130B5212
15.0 (20) 19 16.4 (22) 20 130B5262 130B5247 130B5230 130B5213
18.0 (24) 24 20 (27) 24 130B5263 130B5248 130B5231 130B5214
22.0 (30) 29 24 (32) 29 130B5263 130B5248 130B5231 130B5214
30.0 (40) 36 33 (44) 36 130B5265 130B5250 130B5233 130B5216
37.0 (50) 49 40 (54) 50 130B5266 130B5251 130B5234 130B5217
45.0 (60) 58 50 (65) 58 130B5267 130B5252 130B5235 130B5218
55.0 (75) 74 60 (80) 77 130B5268 130B5253 130B5236 130B5219
75.0 (100) 85 75 (100) 87 130B5269 130B5254 130B5237 130B5220
90 (125) 106 90 (125) 109 130B5270 130B5255 130B5238 130B5221
Table 6.21 Harmonic Filters for 600 V, 60 Hz
Type code and Selection
VLT
®
AQUA Drive FC 202
142 Danfoss A/S © 09/2014 All rights reserved. MG20N622
