Danfoss VLT AQUA Drive FC 202 Design Guide

7.1.4 Line Power Supply 3x380–480 V AC
Type designation PK37 PK55 PK75 P1K1 P1K5
High/normal overload
1)
HO NO HO NO HO NO HO NO HO NO
Typical shaft output [kW] 0.37 0.55 0.75 1.1 1.5
Typical shaft output at 460 V [hp] 0.5 0.75 1.0 1.5 2.0
Protection rating IP20/Chassis
6)
A2 A2 A2 A2 A2
Protection rating IP55/Type 12
Protection rating IP66/NEMA 4X
A4/A5 A4/A5 A4/A5 A4/A5 A4/A5
Output current
Continuous (3x380–440 V) [A] 1.3 1.8 2.4 3.0 4.1
Intermittent (3x380–440 V) [A] 2.0 1.4 2.7 2.0 3.6 2.6 4.5 3.3 6.2 4.5
Continuous (3x441–480 V) [A] 1.2 1.6 2.1 2.7 3.4
Intermittent (3x441–480 V) [A] 1.8 1.3 2.4 1.8 3.2 2.3 4.1 3.0 5.1 3.7
Continuous kVA at 400 V [kVA] 0.9 1.3 1.7 2.1 2.8
Continuous kVA at 460 V [kVA] 0.9 1.3 1.7 2.4 2.7
Maximum input current
Continuous (3x380–440 V) [A] 1.2 1.6 2.2 2.7 3.7
Intermittent (3x380–440 V) [A] 1.8 1.3 2.4 1.8 3.3 2.4 4.1 3.0 5.6 4.1
Continuous (3x441–480 V) [A] 1.0 1.4 1.9 2.7 3.1
Intermittent (3x441–480 V) [A] 1.5 1.1 2.1 1.5 2.9 2.1 4.1 3.0 4.7 3.4
Maximum pre-fuses [A] 10 10 10 10 10
Additional specications
Protection ratings IP20, IP21
maximum cable cross-section
2)
for
line power, motor, brake, and load
sharing [mm
2
] ([AWG])
4, 4, 4 (12, 12, 12)
(minimum 0.2 (24))
Protection ratings IP55, IP66
maximum cable cross-section
2)
for
line power, motor, brake, and load
sharing [mm
2
] ([AWG])
4, 4, 4 (12, 12, 12)
Maximum cable cross-section
2)
for
disconnect [mm
2
] ([AWG])
6, 4, 4 (10, 12, 12)
Estimated power loss
3)
at rated maximum load [W]
4
35 42 46 58 62
Eciency
5)
0.93 0.95 0.96 0.96 0.97
Table 7.7 Line Power Supply 3x380–480 V AC, PK37–P1K5
Specications
VLT
®
AQUA Drive FC 202
154 Danfoss A/S © 09/2014 All rights reserved. MG20N622
77
