Danfoss VLT AQUA Drive FC 202 Design Guide

Type designation P2K2 P3K0 P4K0 P5K5 P7K5
High/normal overload
1)
HO NO HO NO HO NO HO NO HO NO
Typical shaft output [kW] 2.2 3.0 4.0 5.5 7.5
Typical shaft output at 460 V [hp] 2.9 4.0 5.3 7.5 10
Protection rating IP20/Chassis
6)
A2 A2 A2 A3 A3
Protection rating IP55/Type 12
Protection rating IP66/NEMA 4X
A4/A5 A4/A5 A4/A5 A5 A5
Output current
Continuous (3x380–440 V) [A] 5.6 7.2 10 13 16
Intermittent (3x380–440 V) [A] 8.4 6.2 10.8 7.9 15.0 11.0 19.5 14.3 24.0 17.6
Continuous (3x441–480 V) [A] 4.8 6.3 8.2 11 14.5
Intermittent (3x441–480 V) [A] 7.2 5.3 9.5 6.9 12.3 9.0 16.5 12.1 21.8 16.0
Continuous kVA at 400 V [kVA] 3.9 5.0 6.9 9.0 11.0
Continuous kVA at 460 V [kVA] 3.8 5.0 6.5 8.8 11.6
Maximum input current
Continuous (3x380–440 V) [A] 5.0 6.5 9.0 11.7 14.4
Intermittent (3x380–440 V) [A] 7.5 5.5 9.8 7.2 13.5 9.9 17.6 12.9 21.6 15.8
Continuous(3x441–480 V) [A] 4.3 5.7 7.4 9.9 13.0
Intermittent (3x441–480 V) [A] 6.5 4.7 8.6 6.3 11.1 8.1 14.9 10.9 19.5 14.3
Maximum pre-fuses [A] 20 20 20 30 30
Additional specications
Protection ratings IP20, IP21
maximum cable cross-section
2)
for
line power, motor, brake, and load
sharing [mm
2
] ([AWG])
4, 4, 4 (12, 12, 12)
(minimum 0.2 (24))
Protection ratings IP55, IP66
maximum cable cross-section
2)
for
line power, motor, brake, and load
sharing [mm
2
] ([AWG])
4, 4, 4 (12, 12, 12)
Maximum cable cross-section
2)
for
disconnect [mm
2
] ([AWG])
6, 4, 4 (10, 12, 12)
Estimated power loss
3)
at rated maximum load [W]
4)
88 116 124 187 225
Eciency
5)
0.97 0.97 0.97 0.97 0.97
Table 7.8 Line Power Supply 3x380–480 V AC, P2K2–P7K5
Specications Design Guide
MG20N622 Danfoss A/S © 09/2014 All rights reserved. 155
7 7
