Danfoss VLT AQUA Drive FC 202 Design Guide

Type designation P11K P15K P18K P22K P30K
High/normal overload
1)
HO NO HO NO HO NO HO NO HO NO
Typical shaft output [kW] 7.5 11 11 15 15 18.5 22.0 22.0 22.0 30
Typical shaft output at 460 V [hp] 10 15 15 20 20 25 30 30 30 40
Protection rating IP20/Chassis
7)
B3 B3 B3 B4 B4
Protection rating IP21/Type 1 B1 B1 B1 B2 B2
Protection rating IP55/Type 12
Protection rating IP66/NEMA 4X
B1 B1 B1 B2 B2
Output current
Continuous (3x380–440 V) [A] - 24 24 32 32 37.5 37.5 44 44 61
Intermittent (60 s overload)
(3x380–440 V) [A]
- 26.4 38.4 35.2 51.2 41.3 60 48.4 70.4 67.1
Continuous (3x441–480 V) [A] - 21 21 27 27 34 34 40 40 52
Intermittent (60 s overload)
(3x441–480 V) [A]
- 23.1 33.6 29.7 43.2 37.4 54.4 44 64 61.6
Continuous kVA at 400 V [kVA] - 16.6 16.6 22.2 22.2 26 26 30.5 30.5 42.3
Continuous kVA at 460 V [kVA] - 16.7 16.7 21.5 21.5 27.1 27.1 31.9 31.9 41.4
Maximum input current
Continuous (3x380–440 V) [A] - 22 22 29 29 34 34 40 40 55
Intermittent (60 s overload)
(3x380–440 V) [A]
- 24.2 35.2 31.9 46.4 37.4 54.4 44 64 60.5
Continuous (3x441–480 V) [A] - 19 19 25 25 31 31 36 36 47
Intermittent (60 s overload)
(3x441–480 V) [A]
- 20.9 30.4 27.5 40 34.1 49.6 39.6 57.6 51.7
Maximum pre-fuses [A] - 63 63 63 63 80
Additional specications
Protection ratings IP21, IP55, IP66
maximum cable cross-section
2)
for
line power, brake, and load sharing
[mm
2
] ([AWG])
16, 10, 16 (6, 8, 6) 35, -, - (2, -, -)
Protection ratings IP21, IP55, IP66
maximum cable cross-section
2)
for
motor [mm
2
] ([AWG])
10, 10,- (8, 8,-) 35, 25, 25 (2, 4, 4)
Protection rating IP20 maximum
cable cross-section
2)
for line power,
brake, motor, and load sharing
[mm
2
] ([AWG])
10, 10,- (8, 8,-) 35, -, - (2, -, -)
Maximum cable cross-section
2)
for
disconnect [mm
2
] ([AWG])
16, 10, 10 (6, 8, 8)
Estimated power loss
3)
at rated maximum load [W]
4)
291 392 291 392 379 465 444 525 547 739
Eciency
5)
0.98 0.98 0.98 0.98 0.98
Table 7.9 Line Power Supply 3x380–480 V AC, P11K–P30K
Specications
VLT
®
AQUA Drive FC 202
156 Danfoss A/S © 09/2014 All rights reserved. MG20N622
77
