Danfoss VLT AQUA Drive FC 202 Design Guide

7.1.5 Line Power Supply 3x525–600 V AC
Type designation PK75 P1K1 P1K5 P2K2
High/normal overload
1)
HO NO HO NO HO NO HO NO
Typical shaft output [kW] 0.75 1.1 1.5 2.2
Typical shaft output [hp] 1 1.5 2 3
Protection rating IP20/Chassis
Protection rating IP21/Type 1
A3 A3 A3 A3
Protection rating IP55/Type 12 A5 A5 A5 A5
Output current
Continuous (3x525–550 V) [A] 1.8 2.6 2.9 4.1
Intermittent (3x525–550 V) [A] 2.7 2.0 3.9 2.9 4.4 3.2 6.2 4.5
Continuous (3x551–600 V) [A] 1.7 2.4 2.7 3.9
Intermittent (3x551–600 V) [A] 2.6 1.9 3.6 2.6 4.1 3.0 5.9 4.3
Continuous kVA at 550 V [kVA] 1.7 2.5 2.8 3.9
Continuous kVA at 550 V [kVA] 1.7 2.4 2.7 3.9
Maximum input current
Continuous (3x525–600 V) [A] 1.7 2.4 2.7 4.1
Intermittent (3x525–600 V) [A] 2.6 1.9 3.6 2.6 4.1 3.0 6.2 4.5
Maximum pre-fuses [A] 10 10 10 20
Additional specications
Maximum cable cross-section
2)
for line
power, motor, brake, and load sharing
[mm
2
] ([AWG])
4,4,4 (12,12,12)
(minimum 0.2 (24))
Maximum cable cross-section
2)
for line
power disconnect [mm
2
] ([AWG])
6,4,4 (10,12,12)
Estimated power loss
3)
at rated maximum load [W]
4)
35 50 65 92
Eciency
5)
0.97 0.97 0.97 0.97
Table 7.11 Line Power Supply 3x525–600 V AC, PK75–P2K2
