Danfoss VLT AQUA Drive FC 202 Design Guide

Type designation P3K0 P4K0 P5K5 P7K5
High/normal overload
1)
HO NO HO NO HO NO HO NO
Typical shaft output [kW] 3.0 4.0 5.5 7.5
Typical shaft output [hp] 4 5 7.5 10
Protection rating IP20/Chassis
Protection rating IP21/Type 1
A2 A2 A3 A3
IP55/Type 12 A5 A5 A5 A5
Output current
Continuous (3x525–550 V) [A] 5.2 6.4 9.5 11.5
Intermittent (3x525–550 V) [A] 7.8 5.7 9.6 7.0 14.3 10.5 17.3 12.7
Continuous (3x551–600 V) [A] 4.9 6.1 9.0 11.0
Intermittent (3x551–600 V) [A] 7.4 5.4 9.2 6.7 13.5 9.9 16.5 12.1
Continuous kVA at 550 V [kVA] 5.0 6.1 9.0 11.0
Continuous kVA at 550 V [kVA] 4.9 6.1 9.0 11.0
Maximum input current
Continuous (3x525–600 V) [A] 5.2 5.8 8.6 10.4
Intermittent (3x525–600 V) [A] 7.8 5.7 8.7 6.4 12.9 9.5 15.6 11.4
Maximum pre-fuses [A] 20 20 32 32
Additional specications
Maximum cable cross-section
2)
for
line power, motor, brake, and load
sharing
[mm
2
] ([AWG])
4,4,4 (12,12,12)
(minimum 0.2 (24))
Maximum cable cross-section
2)
for
line power disconnect [mm
2
] ([AWG])
6,4,4 (10,12,12)
Estimated power loss
3)
at rated maximum load [W]
4)
122 145 195 261
Eciency
5)
0.97 0.97 0.97 0.97
Table 7.12 Line Power Supply 3x525–600 V AC, P3K0–P7K5
Specications Design Guide
MG20N622 Danfoss A/S © 09/2014 All rights reserved. 159
7 7
