Danfoss VLT AQUA Drive FC 202 Design Guide

Type designation P11K P15K P18K P22K P30K P37K
High/normal overload
1)
HO NO HO NO HO NO HO NO HO NO HO NO
Typical shaft output [kW] 7.5 11 11 15 15 18.5 18.5 22 22 30 30 37
Typical shaft output [hp] 10 15 15 20 20 25 25 30 30 40 40 50
Protection rating IP20/Chassis B3 B3 B3 B4 B4 B4
Protection rating IP21/Type 1
Protection rating IP55/Type 12
Protection rating IP66/NEMA 4X
B1 B1 B1 B2 B2 C1
Output current
Continuous (3x525–550 V) [A] 11.5 19 19 23 23 28 28 36 36 43 43 54
Intermittent (3x525–550 V) [A] 18.4 21 30 25 37 31 45 40 58 47 65 59
Continuous (3x551–600 V) [A] 11 18 18 22 22 27 27 34 34 41 41 52
Intermittent (3x551–600 V) [A] 17.6 20 29 24 35 30 43 37 54 45 62 57
Continuous kVA at 550 V [kVA] 11 18.1 18.1 21.9 21.9 26.7 26.7 34.3 34.3 41.0 41.0 51.4
Continuous kVA at 575 V [kVA] 11 17.9 17.9 21.9 21.9 26.9 26.9 33.9 33.9 40.8 40.8 51.8
Maximum input current
Continuous at 550 V [A] 10.4 17.2 17.2 20.9 20.9 25.4 25.4 32.7 32.7 39 39 49
Intermittent at 550 V [A] 16.6 19 28 23 33 28 41 36 52 43 59 54
Continuous at 575 V [A] 9.8 16 16 20 20 24 24 31 31 37 37 47
Intermittent at 575 V [A] 15.5 17.6 26 22 32 27 39 34 50 41 56 52
Maximum pre-fuses [A] 40 40 50 60 80 100
Additional specications
Protection rating IP20, maximum
cable cross-section
2)
for line
power, brake, motor, and load
sharing [mm
2
] ([AWG])
10, 10,-
(8, 8,-)
35,-,-
(2,-,-)
Protection ratings IP21, IP55, IP66
maximum cable cross-section
2)
for
line power, brake, and load
sharing [mm
2
] ([AWG])
16, 10, 10
(6, 8, 8)
35,-,-
(2,-,-)
Protection ratings IP21, IP55, IP66
maximum cable cross-section
2)
for
motor [mm
2
] ([AWG])
10, 10,-
(8, 8,-)
35, 25, 25
(2, 4, 4)
Maximum cable cross-section
2)
for
line power disconnect [mm
2
]
([AWG])
16, 10, 10
(6, 8, 8)
50, 35, 35
(1, 2, 2)
Estimated power loss
3)
at rated maximum load [W]
4)
220 300 220 300 300 370 370 440 440 600 600 740
Eciency
5)
0.98 0.98 0.98 0.98 0.98 0.98
Table 7.13 Line Power supply 3x525-600 V AC, P11K-P37K
Specications
VLT
®
AQUA Drive FC 202
