Danfoss VLT AQUA Drive FC 202 Design Guide

Description Ordering no.
Uncoated Coated
VLT
®
Backplate in stainless steel IP66/NEMA Type 4X, enclosure size B2
130B3465
VLT
®
Backplate in stainless steel IP66/NEMA Type 4X, enclosure size C1
130B3468
VLT
®
Backplate in stainless steel IP66/NEMA Type 4X, enclosure size C2
130B3491
VLT
®
Probus adapter Sub-D9 connector
130B1112
Probus shield plate kit for IP20, enclosure sizes A1, A2 and A3 130B0524
Terminal block for DC link connection on enclosure sizes A2/A3 130B1064
VLT
®
Screw terminals 130B1116
VLT
®
USB extension, 350 mm (13 in) cable 130B1155
VLT
®
USB extension, 650 mm (25 in) cable 130B1156
VLT
®
Back frame A2 for 1 brake resistor 175U0085
VLT
®
Back frame A3 for 1 brake resistor 175U0088
VLT
®
Back frame A2 for 2 brake resistors 175U0087
VLT
®
Back A3 for 2 brake resistors 175U0086
Local Control Panel
VLT
®
LCP 101 Numeric local control pad
130B1124
VLT
®
LCP 102 Graphical local control pad
130B1107
VLT
®
Cable for LCP 2, 3 m (10 ft)
175Z0929
VLT
®
Panel mounting kit for all LCP types
130B1170
VLT
®
Panel mounting kit, graphical LCP
130B1113
VLT
®
Panel mounting kit, numerical LCP
130B1114
VLT
®
LCP mounting kit, no LCP
130B1117
VLT
®
LCP mounting kit blind cover IP55/66, 8 m (26 ft)
130B1129
VLT
®
Control Panel LCP 102, graphical
130B1078
VLT
®
Blindcover, with Danfoss logo, IP55/66
130B1077
Options for slot A
VLT
®
PROFIBUS DP V1 MCA 101
130B1100 130B1200
VLT
®
DeviceNet MCA 104
130B1102 130B1202
VLT
®
Pronet MCA 120
130B1135 130B1235
VLT
®
Ethernet/IP MCA 121
130B1119 130B1219
VLT
®
Modbus TCP MCA 122
130B1196 130B1296
Options for slot B
VLT
®
General purpose I/O MCB 101
130B1125 130B1212
VLT
®
Relay option MCB 105
130B1110 130B1210
VLT
®
PTC thermistor card MCB 112
130B1137
VLT
®
Extended cascade controller MCO 101
130B1118 130B1218
VLT
®
Sensor input option MCB 114
130B1172 130B1272
VLT
®
Analog I/O option with RTC MCB 109
130B1143 130B1243
Mounting kits for C options
VLT
®
Mounting kit for C option, 40 mm (1.6 in), enclosure sizes A2/A3
130B7530
VLT
®
Mounting kit for C option, 60 mm (2.4 in), enclosure sizes A2/A3
130B7531
VLT
®
Mounting kit for C option, enclosure size A5
130B7532
VLT
®
Mounting kit for C option, enclosure sizes B/C/D/E/F (except B3)
130B7533
VLT
®
Mounting kit for C option, 40 mm (1.6 in), enclosure size B3
130B1413
VLT
®
Mounting kit for C option, 60 mm (2.4 in), enclosure size B3
130B1414
Options for slot C
VLT
®
Advanced cascade controller MCO102
130B1154 130B1254
Type code and Selection
VLT
®
AQUA Drive FC 202
124 Danfoss A/S © 09/2014 All rights reserved. MG20N622
66
