Danfoss VLT AQUA Drive FC 202 Design Guide

525–600 V, Enclosure Sizes A, B, and C
Enclosure Power [kW (hp)] Recommended
fuse size
Recommended
maximum fuse
Recommended circuit
breaker
Moeller
Maximum trip level
[A]
A2 1.1–4.0 (1.5–5) gG-10 gG-25 PKZM0-25 25 (82)
A3 5.5–7.5 (7.5–10) gG-10 (5.5)
gG-16 (7.5)
gG-32 PKZM0-25 25
A5 1.1–7.5 (1.5–10) gG-10 (0.75–5.5)
gG-16 (7.5)
gG-32 PKZM0-25 25
B1 11–18 (15–24) gG-25 (11)
gG-32 (15)
gG-40 (18.5)
gG-80 PKZM4-63 63
B2 22–30 (30–40) gG-50 (22)
gG-63 (30)
gG-100 NZMB1-A100 100
B3 11–18.5 (15–25) gG-25 (11)
gG-32 (15)
gG-63 PKZM4-50 50
B4 22–37 (30–50) gG-40 (18.5)
gG-50 (22)
gG-63 (30)
gG-125 NZMB1-A100 100
C1 37–55 (50–65) gG-63 (37)
gG-100 (45)
aR-160 (55)
gG-160 (37–45)
aR-250 (55)
NZMB2-A200 160
C2 75–90 (100–125) aR-200 (75) aR-250 NZMB2-A250 250
C3 45–55 (60–75) gG-63 (37)
gG-100 (45)
gG-150 NZMB2-A200 150
C4 75–90 (100–125) aR-160 (55)
aR-200 (75)
aR-250 NZMB2-A250 250
Table 7.21 52–-600 V, Enclosure Sizes A, B, and C
Specications Design Guide
MG20N622 Danfoss A/S © 09/2014 All rights reserved. 173
7 7
