Danfoss VLT AQUA Drive FC 202 Design Guide

525–690 V, Enclosure Sizes A, B, and C
Enclosure Power [kW (hp)] Recommended fuse size Recommended
maximum fuse
Recommended circuit
breaker
Danfoss
Maximum trip
level [A]
A3
1.1 (1.5) gG-6 gG-25 CTI25M 10-16 16
1.5 (2) gG-6 gG-25 CTI25M 10-16 16
2.2 (3) gG-6 gG-25 CTI25M 10-16 16
3 (4) gG-10 gG-25 CTI25M 10-16 16
4 (5) gG-10 gG-25 CTI25M 10-16 16
5.5 (7.5) gG-16 gG-25 CTI25M 10-16 16
7.5 (10) gG-16 gG-25 CTI25M 10-16 16
B2
11 (15) gG-25 gG-63
15 (20) gG-25 gG-63
18 (24) gG-32
22 (30) gG-32
C2
30 (40) gG-40
37 (50) gG-63 gG-80
45 (60) gG-63 gG-100
55 (75) gG-80 gG-125
75 (100) gG-100 gG-160
C3
37 (50) gG-100 gG-125
45 (60) gG-125 gG-160
Table 7.22 525–690 V, Enclosure Sizes A, B, and C
