Danfoss VLT AQUA Drive FC 202 Design Guide

Enclosure size [kW (hp)]
A2 A3 A4 A5 B1 B2 B3 B4 C1 C2 C3 C4
1x200–240 V S2 – 1.1 (1.5)
1.1–2.2
(1.5–3)
1.1 (1.5) 1.5–3.7 (2–5) 7.5 (10) – – 15 (20) 22 (30) – –
3x200–240 V T2
0.25–3.0
(0.34–4)
3.7 (5)
0.25–2.2
(0.34–3)
0.25–3.7
(0.34–5)
5.5–11 (7.5–
15)
15 (20)
5.5–11 (7.5–15)
15–18.5 (20–25)
18.5–30
(25–40)
37–45
(50–60)
22–30
(30–40)
37–45 (50–60)
1x380–480 V S4 – –
1.1–4.0
(1.5–5)
– 7.5 (10) 11 (15) – – 18 (24) 37 (50) – –
3x380–480 V T4
0.37–4.0 (5–
5.4)
5.5–7.5 (7.5–10)
0.37–4.0 (5–
5.4)
0.37–7.5
(0.5–10)
11–18.5 (15–
25)
22–30 (30–
40)
11–18.5 (15–25)
22–37 (30–50)
37–55
(50–65)
75–90
(100–
125)
45–55
(60–75)
75–90 (100–125)
3x525–600 V T6 – 0.75–7.5 (1–10) –
0.75–7.5
(1–10)
11–18.5 (15–
25)
22–30 (30–
40)
11–18.5 (15–25)
22–37 (30–50)
37–55
(50–65)
75–90
(100–
125)
45–55
(60–75)
75–90 (100–125)
3x525–690 V T7 – – – – –
11–30 (15–
40)
– – –
37–90
(50–125)
– –
Distance between mounting holes
b
70
(2.76)
70
(2.76)
110
(10.33)
110 (4.33) 171 (6.73) 215 (8.47) 210 (8.27) 210 (8.27)
140
(5.51)
200
(7.87)
272
(10.71)
334
(13.15)
270
(10.63)
330 (13)
Depth
1)
[mm (in)]
Without option A/B C
205
(8.07)
205
(8.07)
205
(8.07)
205 (8.07) 175 (6.89) 200 (7.87) 260 (10.24) 260 (10.24)
248
(9.76)
242
(9.53)
310
(12.21)
335
(13.19)
333
(13.11)
333
(13.11)
With option A/B C
220
(8.66)
220
(8.66)
220
(8.66)
220 (8.66) 175 (6.89) 200 (7.87) 260 (10.24) 260 (10.24)
262
(10.32)
242
(9.53)
310
(12.21)
335
(13.19)
333
(13.11)
333
(13.11)
Screw holes [mm (in)]
c
8.0
(0.315)
8.0
(0.315
)
8.0
(0.315)
8.0
(0.315)
8.25 (0.325) 8.2 (0.323) 12 (0.47) 12 (0.47) 8 (0.315) - 12 (0.47) 12 (0.47) - -
d
[m
m
(in
)]
ø11
(0.43)
ø11
(0.43)
ø11
(0.43)
ø11 (0.43) ø12 (0.47) ø12 (0.47) ø19 (0.75) ø19 (0.75) 12 (0.47) -
ø19
(0.75)
ø19
(0.75)
- -
e
ø5.5
(0.217)
ø5.5
(0.217
)
ø5.5
(0.217)
ø5.5
(0.217)
ø6.5 (0.256)
ø6.5
(0.256)
ø9 (0.354) ø9 (0.354)
6.8
(0.267)
8.5
(0.335)
ø9.0
(0.354)
ø9.0
(0.354)
8.5
(0.335)
8.5
(0.335)
f
9
(0.354)
9
(0.354
)
9 (0.354) 9 (0.354) 6 (0.236) 9 (0.354) 9 (0.354) 9 (0.354)
7.9
(0.311)
15 (0.59)
9.8
(0.386)
9.8
(0.386)
17 (0.67) 17 (0.67)
Specications
VLT
®
AQUA Drive FC 202
180 Danfoss A/S © 09/2014 All rights reserved. MG20N622
77
