Danfoss VLT AQUA Drive FC 202 Design Guide

RFI lter type Conducted emission Radiated emission
Cable length [m (ft)] Cable length [m (ft)]
Standards
and
require-
ments
EN 55011 Class B Class A
Group 1
Class A
Group 2
Class B Class A
Group 1
Class A
Group 2
Housing,
trades and
light
industries
Industrial
environment
Industrial
environ-
ment
Housing,
trades and
light
industries
Industrial
environment
Industrial
environment
EN/IEC 61800-3 Category C1 Category C2 Category C3 Category C1 Category C2 Category C3
First
environment
Home and
oce
First
environment
Home and
oce
Second
environ-
ment
Industrial
First
environment
Home and
oce
First
environment
Home and
oce
Second
environment
Industrial
H1
FC 202
0.25–45 kW (0.34–60
hp) 200–240 V
T2 50 (164) 150 (500) 150 (500) No Yes Yes
1.1–7.5 kW (2–10 hp)
200–240 V
S2 50 (164)
100/150
(330/500)
5)
100/150
(330/500)
5)
No Yes Yes
0.37–90 kW (0.5–125
hp) 380–480 V
T4
50 (164) 150 (500) 150 (500) No Yes Yes
7.5 kW (10 hp) 380-480
V
S4
50 (164)
100/150
(330/500)
5)
100/150
(330/500)
5)
No Yes Yes
H2
FC 202 0.25–3.7 kW (0.34–5 hp)
200–240 V
T2 No No 5 (16.4) No No No
5.5–45 kW (7.5–60 hp)
200–240 V
T2
No No 25 (82) No No No
1.1–7.5 kW (2–10 hp)
200–240 V
S2 No No 25 (82) No No No
0.37–7.5 kW (0.5–10 hp)
380–480 V
T4
No No 5 (16.4) No No No
11–90 kW (15–125 hp)
380–380 V
4)
T4 No No 25 (82) No No No
7.5 kW (10 hp) 380-480
V
S4 No No 25 (82) No No No
11–30 kW (15–40 hp)
525–690 V
1, 4)
T7 No No 25 (82) No No No
37–90 kW (50–125 hp)
525–690 V
2, 4)
T7 No No 25 (82) No No No
H3
FC 202
0.25–45 kW (0.34–60
hp) 200–240 V
T2
10 (33) 50 (164) 50 (164) No Yes Yes
0.37–90 kW (0.5–125
hp) 380–480 V
T4
10 (33) 50 (164) 50 (164) No Yes Yes
H4
FC 202
1.1–30 kW (1.5–40 hp)
525–690 V
1)
T7 No 100 (330) 100 (330) No Yes Yes
37–90 kW (50–125 hp)
525–690 V
2)
T7 No 150 (500) 150 (500) No Yes Yes
Hx
1)
System Integration
VLT
®
AQUA Drive FC 202
