Danfoss VLT AQUA Drive FC 202 Design Guide

•
For powering customer-supplied accessory
devices such as sensors, PLC I/O, contactors,
temperature probes, indicator lights, and/or other
electronic hardware.
•
Diagnostics include a dry DC-ok contact, a green
DC-ok LED, and a red overload LED.
External temperature monitoring
•
Designed for monitoring temperatures of external
system components, such as the motor windings
and/or bearings. Includes eight universal input
modules plus two dedicated thermistor input
modules. All 10 modules are integrated into the
adjustable frequency drive’s safe torque o circuit
and can be monitored via a serial communication
bus network (requires the purchase of a separate
module/bus coupler). Order a safe torque o
brake option to select external temperature
monitoring.
Serial communications
PROFIBUS DP V1 MCA 101
•
PROFIBUS DP V1 gives wide compatibility, a high
level of availability, support for all major PLC
vendors, and compatibility with future versions.
•
Fast, ecient communication, transparent instal-
lation, advanced diagnosis and parameterization
and auto-conguration of process data via GSD-
le.
•
A-cyclic parameterization using PROFIBUS DP V1,
PROFIdrive or Danfoss FC
prole state machines,
PROFIBUS DP V1, Master Class 1 and 2 Ordering
number 130B1100 uncoated – 130B1200 coated
(Class G3/ISA S71.04-1985).
DeviceNet MCA 104
•
This modern communications model oers key
capabilities that allow operators eectively
determine what information is needed and when.
•
It benets from ODVA’s strong conformance
testing policies, which ensure that products are
interoperable. Ordering number 130B1102
uncoated 130B1202 coated (Class G3/ISA
S71.04-1985).
PROFINET RT MCA 120
The PROFINET option oers connectivity to PROFINET-
based networks via the PROFINET protocol. The option is
able to handle a single connection with an actual packet
interval down to 1 ms in both directions.
•
Built-in web server for remote diagnosis and
reading out of basic adjustable frequency drive
parameters.
•
An e-mail notication can be congured for
sending an e-mail message to one or several
receivers, if certain warnings or alarms occur, or
have cleared again.
•
TCP/IP for easy access to adjustable frequency
drive conguration data from MCT 10 Set-up
Software.
•
FTP (File Transfer Protocol) le uploaded and
download.
•
Support of DCP (discovery and conguration
protocol).
EtherNet IP MCA 121
EtherNet becomes the future standard for communication
on the factory oor. The EtherNet option is based on the
newest technology available for the Industrial use and
handles even the most demanding requirements.
EtherNet/IP extends commercial o the-shelf EtherNet to
the common industrial protocol (CIP™) the same upper-
layer protocol and object model found in DeviceNet. The
MCA 121
oers advanced features as:
•
Built-in high performance switch enabling line-
topology, and eliminating the need for external
switches.
•
Advanced switch and diagnosis functions.
•
A built-in web server.
•
An e-mail client for service notication.
Modbus TCP MCA 122
The Modbus option oers connectivity to Modbus TCP-
based networks, such as Groupe Schneider PLC system via
the Modbus TCP Protocol. The option is able to handle a
single connection with an actual packet interval down to 5
ms in both directions.
•
Built-in web-server for remote diagnosis and
reading out basic adjustable frequency drive
parameters.
•
An e-mail notication can be congured for
sending an e-mail message to one or several
receivers, if certain warnings or alarms occur, or
have cleared again.
•
2 Ethernet ports with built-in switch.
•
FTP (le transfer protocol) le uploaded and
download.
•
Protocol automatic IP address conguration.
More Options
General purpose I/O MCB 101
The I/O option oers an extended number of control
inputs and outputs.
•
3 digital inputs 0–24 V: Logic 0<5 V; Logic 1>10 V
•
2 analog inputs 0–10 V: Resolution 10 bit plus
sign
System Integration
VLT
®
AQUA Drive FC 202
