Pneumatic system (optional): the machine’s pneumatic system is equipped with a
complete air treatment group consisting of a manual command valve that cuts off
pneumatic power feed (1 fig. 2.6.1.1J) with a pressure discharge, pressure regulating
filter and manometer (2 fig. 2.6.1.1J).
Fig. 2.6.1.1J Pneumatic system
ATTENTION The air resulting from the power supply must be filtered and
dried using special devices, before entering the air treatment unit of the
packaging machine.
