Pag 35 / 154
Manuale Lyra 600 sx elettr eng
2.7.1 Dangerous points or zones on the machine
The following tables show the residual risks present on the machine, and identify these
dangerous zone and points, the operations associated with dangerous situations, and the
type of correlated risk.
Mechanical type of hazards.
Collisions due to machine elements in motion.
Danger zone related
to cause of danger
On the pusher rods (1 fig. 2.7.1.1A) of the infeed conveyor in the
product manual loading zone.
Phase of the
operating cycle
Entering the danger zone with the machine running..
During the packaging cycle the frequency is continuous if the
loading of the product to be packed is done manually.
The danger zone of the infeed conveyor is not protected by
guards.
Very slight injuries to fingers and hands.
Fig. 2.7.1.1A Position of residual risk no 1
