Dräger Julian - Sensor and Measurement Setup

Monitoring
SpO2 Measurement
76
SpO2 Measurement (optional)
Sensor selection
Only use Nellcor sensors.
Note the Instructions for Use of the sensors –
incorrect positioning or use can cause tissue damage.
Select the sensor according to the following criteria:
– Patient weight
– Patient mobility
– Possible application site
– Patient perfusion
– Duration of use
The following table listing the specific sensor types
available and their characteristics is intended as an aid
for selection.
OXISENSOR  I-20, OXISENSOR  D-20,
DURASENSOR  DS-100 A, OXISENSOR  D-25 and
OXISENSOR  R-15 are registered trademarks.
–––––––––––––
1)
in unopened, undamaged packaging
Sensor type OXISENSOR OXISENSOR DURASENSOR OXISENSOR OXISENSOR
I-20 D-20 DS-100 A D-25 R-15
Age group Infants Children Adults Adults Adults
Patient 1 to 20 kg 10 to 50 kg >40 kg >30 kg >50 kg
weight
Duration Short and long-term Short and long-term Short-term Short and long-term Short and long-term
of use monitoring monitoring monitoring zeitüberwachung monitoring
Patient Limited Limited Immobile Limited Immobile
mobility mobility mobility patients only mobility patients only
Preferred Toe Finger Finger Finger Nose
measuring site
Sterility
1)
Sterile packaging Sterile packaging ____ Sterile packaging Sterile packaging
"Only for internal use by Draeger. Not applicable as Instructions for Use!"
