Configuring in Standby Mode
Setting default values
Record
This function is used to determine the type of event that
triggers an entry in the record list or a printout on the
connected record printer.
● Select the line »record« with the rotary knob and
press to confirm.
The »record« menu appears on the left-hand side.
Display (example):
Time
interval-started (min)
A list entry is activated after a fixed time interval in
minutes.
NiBP-started
An entry is made after every NiBP measurement with new
measured values. This entry can be read by an external
Dräger monitor via the MEDIBUS interface.
Warning-started
An entry is made whenever an alarm is triggered.
Caution-started
An entry is made whenever a caution message is
triggered.
● Turn the rotary knob to select the event triggering the
entry and press to confirm.
Configuring the interfaces
Julian has three serial interfaces:
COM1, COM2, COM3.
COM2 and COM3 are configured as MEDIBUS*
interfaces and COM1 as printer interface. The interfaces
can be adapted to the connected equipment.
● Turn the rotary knob to select the line »interfaces«
and press to confirm.
The »interfaces« menu appears in the left-hand field.
Display (example):
COM2 is configured in the upper half of the menu and
COM1 and COM3 in the bottom half.
_____________
* MEDIBUS: Dräger communications protocol for medical equipment.
