Vigor2760 Series User’s Guide
213
will be replaced by the prefix number for calling out
through the specific VoIP interface. Take the above picture
(Prefix Table Setup web page) as an example, the prefix
number of 03 will be replaced by 8863. For example: dial
number of “031111111” will be changed to
“88631111111” and sent to SIP server.
OP Number
The front number you type here is the first part of the
account number that you want to execute special function
(according to the chosen mode) by using the prefix
number.
Min Len
Set the minimal length of the dial number for applying the
prefix number settings. Take the above picture (Prefix
Table Setup web page) as an example, if the dial number is
between 7 and 9, that number can apply the prefix number
settings here.
Max Len
Set the maximum length of the dial number for applying
the prefix number settings.
Route
Choose the one that you want to enable the prefix number
settings from the saved SIP accounts. Please set up one
SIP account first to make this interface available. This item
will be changed according to the port settings configured
in VoIP>> Phone Settings.
Apply
Click it to save the settings.
Clear
Click it to remove the modification of the web page.
Cancel
Click it to return to previous web page.
3. After finished the settings above, click Apply to save the file. Now, the digit map profile
has been modified.
