19.6.2 Setting the Thread clamp (Thread Clamp) parameter
Various settings can be made for the thread clamp. The possibilities are
explained in more detail in the table.
StitchLengthChg On/Off
Optimization of the remaining thread length for the cutting systems
(KFA = 1, extra short; LFA = 10, extra long)
St.Length
(Value range 01 – 10)
On°
(Value range 000 – 359 [°])
Off°
(Value range 000 – 359 [°])
Trim Backward Thread cutting during backward stitch.
(Value range: On/Off)
PWM Config Pulse width modulation
Power supply to the magnet for the thread cutter.
t1 [ms]
Activation duration of the thread cutter in time period t1.
(Value range 000 – 1000 [ms])
DtyC. t1 [%]
Duty cycle in time period t1
(Value range 000 – 1000 [%])
t2 [s]
Activation duration of the thread cutter in time period t2.
(Value range 000 – 1000 [ms])
DtyC. t2 [%]
Duty cycle in time period t2
(Value range 000 – 1000 [%])
Menu item Setting option
Menu item Setting options
Mode Various modes (1 to 10) are available; explanations can be found
in the  Parameter list 869-M PREMIUM.
Mat.Thickness Compensation of the material thickness
(Value range: On/Off)
Clamp Angle On/Off
Position for activating and deactivating the thread clamp.
(Value range 000 – 359)
Foot Angle On/Off
Position for lifting/lowering the sewing feet, to release a thread
jammed underneath.
(Value range 000 – 359)
Height
Lifting height of the sewing feet.
(Value range 01.0 – 12.0)
