Programming
104 Service Instructions 869-M PREMIUM - 00.0 - 07/2018
19.6.8 Setting the Stitch length (Stitchlen.) parameter
Various settings can be made for the stitch length. The possibilities are
explained in more detail in the table.
19.6.9 Setting the Bobbin (Bobbin) parameter
Various settings can be made for the bobbin. The possibilities are explained
in more detail in the table.
NOTICE
Property damage may occur!
The machine and the sewing equipment may be damaged.
ALWAYS enter the maximum possible stitch length after changing
the sewing equipment.
Menu item Setting options
Max St.Len Maximum stitch length possible during sewing; this will vary depend-
ing on the sewing equipment and MUST be adjusted when changing
the sewing equipment.
When the value is changed, the machine requests a reset, i.e.
switching off and on again. Cf.  p. 23.
(Value range 02.0 - 12.0 [mm], depending on the subclass)
Man.St.Len. Stitch adjustment lever for manual adjustment of the stitch length
active or inactive; optional equipment.
(Value range: On/Off)
Speed
Limitatio
St.Len.
The speed is limited during sewing as from the set stitch length value.
(Value range 1.0 - 12.0 [mm], depending on the subclass)
Speed
Value for limiting the speed as from a defined, adjustable stitch length.
(Value range 0050 - 3800 [rpm], depending on the subclass)
Menu item Setting options
Bobbin Monit Activation of the bobbin rotation monitor
0 = PCB 9850 867003
1 = CAN version (right bobbin)
SSD Enlacement check
(Value range: On/Off)
