19.6.3 Setting the Speed (Speed) parameter
Various settings can be made for the speed. The possibilities are explained
in more detail in the table.
19.6.4 Setting the Stop positions (Stop Positions) parameter
Various settings can be made for the stop positions. The possibilities are
explained in more detail in the table.
Menu item Setting options
Max Speed Maximum permissible speed; it can no longer be exceeded on the
operator level.
(Value range 0500 - 3800 [rpm], depending on the subclass)
Min. Speed Minimum speed at which an individual stitch is made; a lower speed is
no longer possible at operator level.
(Value range 050 – 400 [rpm])
Pos. Speed Position speed; the last stitch is made slower during stopping of the
sewing procedure.
(Value range 010 – 700 [rpm])
Soft Speed Speed for the soft start.
(Value range 0010 – 1000 [rpm])
N Stitches Number of stitches to be made during a soft start.
(Value range 00 – 10)
Acceleration Slope of the acceleration ramp
(Value range 10 - 40 [rpm/ms])
Deceleration Slope of the deceleration ramp
(Value range 10 - 40 [rpm/ms])
Menu item Setting options
StopBottom° Holding position of the needle in the material.
Value range (000 – 359)
Threading° Position for the proper function of the threader, e.g. with thread lever at
top dead center.
Value range (000 – 359)
StopTop° Holding position of the needle outside of the material.
Value range (000 – 359)
StopIdle° Stop position after thread cutting (reversal position).
Value range (000 – 359)
