Programming
110 Service Instructions 869-M PREMIUM - 00.0 - 07/2018
19.6.17 Setting the Correction of effects of high speed
(Speed Corr.) parameter
Various settings can be made for the correction of the effects of high
speed. The possibilities are explained in more detail in the table.
19.6.18 Setting the Light barrier (LightBarrier) parameter
Various settings can be made for the light barrier. The possibilities are
explained in more detail in the table.
Menu item Setting options
Hysterese Tolerance at which the correction of the effects of high speed based on
the second stitch length, the second needle thread tension and/or the
second sewing foot stroke switches back. This tolerance is designed to
ensure that there is no constant alternating between activation and
deactivation in the boundary range.
(Value range 0.0 – 2.0 [mm])
Menu item Setting options
On/Off Light barrier active/inactive.
Speed The last stitches after the detection of the end of the material
(approx. 50 mm) can be sewn at a defined speed.
(Value range 0010 – 2000 [rpm])
Fr.pedal.start Free
Pedal start
On
Pedal can be pressed and the machine sews as soon as the
material breaks the light barrier
Off
Pedal is pressed but the machine does not start sewing; must be
started from neutral position
Sense Dark
The signal is given when the light barrier is broken.
Bright
The signal is given when the light barrier is complete.
Automatic This setting is relevant only the material end detection is activated
on the Operator level.
On
The pedal starts a program, which runs automatically.
Off
The pedal starts a program; the user determines the speed through
the end of the program.
