Programming
Service Instructions 869-M PREMIUM - 00.0 - 07/2018 133
19.11.1 Setting the All data (All Data) parameter
All data – i.e. parameter settings, programs, and calibration values – are
transfered to the USB key or the control.
To transfer all data:
1. Plug the USB key into the socket (1) on the control (2).
Fig. 98: Data Transfer submenu
2. Call up the Service > Data Transfer > All Data menu item.
3. Press the OK button to confirm the selection.
4. Use the
▲/▼ buttons to choose between the options Load from USB
or Store to USB.
5. Press the OK button to confirm.
The following warning message appears:
Fig. 99: Data loss warning message
6. To cancel, press the ESC button; to continue, press the OK button.
The data transfer begins and a message appears, stating that the
USB key must not be removed:
(1) - Connection (2) - Control
OK ESC
USB-Stick löschen
