Programming
Service Instructions 869-M PREMIUM - 00.0 - 07/2018 107
19.6.13 Setting the Seam center guide (Center Guide) parameter
The seam center guide is optional additional equipment on 2-needle
machines. When the seam center guide is activated, the following settings
can be made.
19.6.14 Setting the Puller (Puller) parameter
The puller is an optional piece of additional equipment that supports the
transport of the sewing material. When the puller is active, you can define
the following settings.
Menu item Setting options
Auto Mode for automatic raising of the seam center guide.
Off
Raising of the seam center guide is deactivated; it is not raised
automatically.
OnTack
Raising of the seam center guide when sewing the bartack.
OnLift
Raising of the seam center guide when lifting the sewing foot.
Tack+Lift
Raising of the seam center guide when sewing the bartack and lifting
the sewing foot.
RaiseOnHP When the 2nd stroke height is activated, the seam center guide is
automatically raised.
(Value range: On/Off)
Menu item Setting options
On/Off Puller active or inactive
Lift Mode for raising the puller automatically.
Off
Raising of the puller is deactivated; it is not raised automatically.
OnLift
Raising of the puller when lifting the sewing foot.
OnTack
Raising of the puller when sewing the bartack.
Tack+Lift
Raising of the puller when sewing the bartack and lifting the sewing
foot.
RaiseOnHP When the second stroke height is activated, the puller is automatically
raised.
(Value range: On/Off)
Delay Lowering of the roller after seam beginning; depends on stitch length
and application.
(Value range 000.0 – 999.9 [mm])
