Programming
108 Service Instructions 869-M PREMIUM - 00.0 - 07/2018
Mode Setting defining which puller roller is supposed to run.
Mechanic
Both rollers freewheel passively; mechanical coupling only
Top+Bot
Both wheels run actively under power
Upper
The upper roller runs actively under power
Transport Transport mode of the rollers
constant
Even transport
intermittent
Transport adapted to the rhythm of the machine's feed dog
Setting of the start and stop angle under Start/Stop has been
adapted to the machine. The values should not be changed.
Pressure Set the puller pressure
Yes
Pressure is supplied constantly and regulated via the gage at the puller.
HPNo
Pressure is generated actively except for the 2nd stroke height.
No
No active pressure from puller.
SwitchOff Puller is not active when the sewing motor is stopped. Holding force
of the roller is off; sewing material can be pulled out from between
the rollers.
AlwaysOn Puller is always on even when raised.
Top Settings of the upper puller roller.
Transm. Transmission, puller
(Value range 00.0 – 65.0)
Drive Motor current, puller
(Value range 0.0 - 5.0 [A])
Hold No-damage current, puller
(Value range 0.0 - 5.0 [A])
Diameter Diameter, roller
(Value range 0000 – 9999 [mm])
Direction Rotational direction, roller
0 = right
1=left
ClosedLoop 0 = non-regulated (controlled operation)
1 = regulated
Down Settings of the lower puller roller - identical to the settings of the upper
puller roller.
Menu item Setting options
