Programming
Service Instructions 869-M PREMIUM - 00.0 - 07/2018 113
Fig. 84: Example ParameterView active
When ParameterView is active, the item ParameterCall is added to
the menus in both Manual mode and Automatic mode. This function is
described separately ( p. 92).
19.7.3 Setting the Input configuration (Input Config) parameter
Configure and allocate the inputs here. The table shows the inputs and
their allocation.
Machine input signal Input
Buttons on the button bar
S1 X120T.3
S2 X120T.16
S3 X120T.4
S4 X120T.17
S5 X120T.5
S6 X120T.18
Knee button S1 X120T.15
Knee button S2 X120T.2
Electronic handwheel S1 X100B.15
Operation lock input
(input on the circuit board)
X120B.2
DB3000 IN (X23)
(input on the circuit board)
X120B.15
Light barrier (X21) (optional) X100B.4
Additional button S1 (optional) X120B.16
Additional button S2 (optional) X120B.4
An/Aus.........
Start FA° 125
Stopp FA° 20
°
Drehzahl 150
T0203
T0200
T0210
T0211
