Programming
124 Service Instructions 869-M PREMIUM - 00.0 - 07/2018
19.8 Service submenu
Make technical settings here, so that the machine runs without any prob-
lems. The parameters are explained in more detail in the subchapters.
The menu is divided into the following submenus:
19.8.1 Setting the Multitest (Multitest) parameter
This parameter makes it possible to test whether, for example, magnets,
drives, and inputs or outputs are functioning correctly. Parameter
Sheet 869-M PREMIUM lists the necessary allocations.
Test Output subitem
Test of the outputs according to the wiring diagram.
To test the outputs:
1. Select the desired output with the
/ buttons.
Fig. 90: Test Output subitem
Parameter Explanation Reference
Multitest Multitest p. 124
Settings Service routine p. 128
Calibration Calibration p. 128
Error Log Error list p. 131
Subitem Explanation Reference
Test Output Test of the outputs p. 124
Test PWM Test of the pulse width modulation p. 125
Test Input Test of the inputs p. 125
Test Ana. Input Test of the analog inputs p. 126
Test Auto Input Test of the inputs p. 126
Test Sew. Motor Test of the sewing motor p. 126
Test Step. Motor Test of the stepper motors p. 127
Test Pedal Test of the analog pedal p. 128
Test Fabric Sen Test of the material thickness detection (sensing) p. 128
