19.6.11 Setting the Pedal (Pedal) parameter
Various settings can be made for the pedal. The possibilities are explained
in more detail in the table.
19.6.12 Setting the Needle cooling (NeedleCooling) parameter
Various settings can be made for the needle cooling. The possibilities are
explained in more detail in the table.
Menu item Setting options
Type DA Analog/Digital
Choice between an analog and digital pedal.
Inverted Inversion of the signals given by the pedal (possibly necessary
for digital setpoint devices).
(Value range: On/Off)
N StepsPedal Number of speed steps processed by the pedal.
(Value range 00 – 64)
Curve Speed curve of the pedal.
t Posit. -1 Debouncing of position -1
(Value range 000 – 255 [ms])
t Posit. -2 Debouncing of position -2
(Value range 000 – 255 [ms])
t Posit. 0 Debouncing of position 0
(Value range 000 – 255 [ms])
Menu item Setting options
Off Needle cooling is deactivated.
On Needle cooling is activated.
t After Sew
Lag time, after which the needle cooling is deactivated.
(Value range 00.0 – 10.0 [ms])
AtSpeed t After Sew
Lag time, after which the needle cooling is deactivated.
(Value range 00.0 – 10.0 [ms])
CoolSpeed
Speed at which the needle cooling is activated.
(Value range 0000 – 6000 [rpm])
Edge cutter Needle cooling is activated when the edge cutter is also activated.
t After Sew
Lag time, after which the needle cooling is deactivated.
(Value range 00.0 – 10.0 [ms])
