Programming
114 Service Instructions 869-M PREMIUM - 00.0 - 07/2018
A mode can be allocated to every input (parameter T 53 00). The following
table lists the modes:
Menu item Setting options
Mode 0, 7, 9, 10, 13,
14, 16, 17, 19,
22, 24
No function assigned
1 Threading position
2 Bartack active/inactive.
3 Manual bartack
4Half stitch
5 Full stitch
6 Point position
8 Needle height
11 2. Needle thread tension
12 Change of stitch length
15 Seam center guide/puller
18 Light barrier
20 Operation lock when contact is opened normally (NO)
21 Quick stroke height adjustment
23 Change to next seam section
25 2. Position of edge guide
26 Sewing feet lift position (shoe machines)
27 Additional fullness
28 Tension tape
29 Puller
31 Operation lock when contact is closed (N.C.)
32 Operation lock in the seam (stop after bartack or
thread cutter (N.C.))
Stored On - stored
Off - not stored
