Programming

Service Instructions 869-M PREMIUM - 00.0 - 07/2018 117

Fig. 86: Wiring - plug X83B

Fig. 87: Wiring - plug X83T

Fig. 88: Example of adapter for PLC and DACcomfort

X80B

1 (+24V)

2 (IN1)

3 (IN3)

4 (IN5)

5 (IN7)

8 (+24V)

9 (OUT1)

10 (OUT3)

11 (OUT5)

12 (OUT7)

13 (GND)

(GND) 14

(IN2) 15

(IN4) 16

(IN6) 17

(IN8) 18

(GND) 19

(+24V) 21

(OUT2) 22

(OUT4) 23

(OUT6) 24

(OUT8) 25

X80T

1 (+24V)

2 (IN9)

3 (IN11)

4 (IN13)

5 (IN15)

8 (Umag)

9 (OUT9)

10 (OUT11)

11 (OUT13)

12 (OUT15)

13 (GND)

(GND) 14

(IN10) 15

(IN12) 16

(IN14) 17

(IN16) 18

(GND) 19

(Umag) 21

(OUT10) 22

(OUT12) 23

(OUT14) 24

(OUT16) 25
