Dynon Avionics SkyView - Page 105

SV-EMS-220 Installation and Configuration
SkyView System Installation Guide - Revision K 7-19
Example Jabiru 2200
Pin
EMS 37-pin Harness
Wire Color
Sensor (with Dynon part number if
applicable)
1
Red
Battery voltage (voltmeter input)
2
Yellow or Unwired
Not connected
3
Black
Ground
4
Purple/Blue
Elevator position potentiometer
5
Black
Ground
6
White/Yellow
Jabiru oil pressure
7
White/Brown
Jabiru oil temperature
8
Brown
Fuel pressure (100411-000 or 101690-000)
9
Brown/Blue
Heated pitot status (contact input)
10
Brown/Yellow
Not connected
11
Orange
Not connected
12
Yellow
Not connected
13
Black
Ground
14
Yellow
Fuel flow (100403-003)
15
Red
Not connected
16
Black
Ground
17
Black
Ground
18
White/Red
Kavlico Pressure Sensors
19
White/Black
Not connected
20
Orange/Brown
Fuel level left (resistive)
21
Orange/Blue
Fuel level right (resistive)
22
Purple/Yellow
Flaps position potentiometer
23
Purple/Green
Not connected
24
Orange/Green
Ammeter shunt + (100412-000)
25
Orange/Purple
Ammeter shunt -
26
Green/Red
Not connected
27
Open
Not connected
28
Open
Not connected
29
Yellow/Green
Optional External Alarm Light
30
Black
Not connected
31
White/Orange
Not connected
32
White/Green
RPM Left (standard)
33
White/Blue
RPM Right (standard)
34
Blue
Not connected
35
Green
Not connected
36
Blue or Unwired
Not connected
37
Green or Unwired
Not connected
Table 26–Example Jabiru 2200 37-pin Connector Sensor Map
