SkyView System Installation Guide - Revision K 5-1
5. SV-ADAHRS-20X Installation and Configuration
The SkyView ADAHRS module uses MEMS sensor technology to accurately measure inertial,
magnetic, and air data. To ensure accuracy in its readings, it is very important that you install
the module correctly and perform the specified calibration steps. This chapter guides you
through that process.
Dynon sells a primary ADAHRS model (SV-ADAHRS-200) and a backup model (SV-ADAHRS-201).
Throughout the guide, these models are collectively referred to as “SV-ADAHRS-20X.” The
primary and backup models are identical in functionality.
Read and understand the System Planning Chapter before installing the ADAHRS.
If you have more than one ADAHR in your SkyView system, all ADAHRS calibrations
are applied to all ADAHRS simultaneously. In other words, you generally only need
to go these steps once per system, provided all ADAHRS are calibrated, installed
and are connected via SkyView Network. However, if an additional SV-ADAHRS-
20X is installed and configured at a time after the original installation and
calibrations in this chapter have been performed, all setup and calibration steps in
this section of the SkyView Installation manual should be performed as if the
ADAHRS is being installed for the first time.
