SV-EMS-220 Installation and Configuration
7-46 SkyView System Installation Guide - Revision K
 1400-1800 and 2500-4000 RPM in YELLOW
 1800-2500 RPM in GREEN
When OIL TEMP > 120ºF, the TACHOMETER displays different ranges:
 0-1400 and 5800-6000 RPM in RED
 1400-1800 and 5500-5800 RPM in YELLOW
 1800-5500 RPM in GREEN
At 0 RPM, tachometer alerting is inhibited. When RPM advances above 0, the tachometer alert
is inhibited for 10 seconds to avoid nuisance alarms as the engine starts.
The alarm type for the tachometer is the “self-clearing” type.
Oil Temperature Gauge for Rotax 912:
When OIL TEMP < 190ºF, the OIL TEMP gauge displays these ranges:
 100-120 and 230-266ºF in YELLOW
 120-190ºF in GREEN if OIL TEMP has been above 190ºF “more recently” than OIL TEMP
was below 120ºF; otherwise 120-190ºF is displayed in BLACK OUTLINED IN WHITE
 190-230ºF in GREEN
 266-280ºF in RED.
When OIL TEMP is > 190ºF, the OIL TEMP gauge will display different ranges:
 100-120 and 230-266ºF in YELLOW
 120-230ºF in GREEN
 266-280ºF in RED
The alarm type for oil temperature is the “self-clearing” type.
EMS Sensor Definitions, Mapping, and Settings
All sensors must be defined, mapped to SV-EMS-220 pins, and have their settings
configured. This section describes how sensors are defined, mapped, and set in
SkyView.
EMS Sensor Definitions
All EMS sensor installations require a SkyView Sensor Definitions file. This file is preloaded onto
each display prior to shipment and contains all of the sensor types that SkyView supports. It
may be updated in the future to include more sensors. This file is downloadable at
downloads.dynonavionics.com.
If you need to update the SkyView Sensor Definitions file, download the file and use the
instructions found in the How to Load and Delete Files Section.
