` Appendix C: Wiring and Electrical Connections
SkyView System Installation Guide - Revision K 17-3
SkyView D37
Connector Pin
Table 53 - SV-BAT-320 Wiring
OAT Connection
For customers that are converting from other Dynon products, you can use your installed OAT
with the addition of the connector below. Both 100433-000 and 100433-001 are compatible.
The OAT wiring can be extended as required. If you have 100433-001, ignore the red wire and
connect the yellow and blue wires to the connector below. The OAT is non-polarized; either
wire can connect to either pin.
Connector: Molex Micro-Fit P/N 43645-0200 (Digi-Key P/N WM1845-ND)
Pins: Molex Micro-Fit P/N 43030-0007 (Digi-Key P/N WM1837-ND)
Wire: 22 AWG Tefzel
SkyView Equipment Electrical Connections
A SkyView display (SV-D700 and SV-D1000) has six connectors on the back of the unit as
illustrated in Figure 86:
One male D37 for connection to the SkyView Display Harness (SV-HARNESS-D37)
Two male D9 SkyView network connectors
Two Standard 4-pin USB 2.0 jacks for use with USB Series A plugs. Note that there is also
a USB port on the SV-HARNESS-D37 for convenience.
One standard 8-pin RJ45 connector for use with twisted pair category 5 Ethernet cable
