SV-D700 / SV-D1000 Installation and Configuration
4-22 SkyView System Installation Guide - Revision K
Minimum Brightness Voltage–This is a voltage that represents the external control
signal’s minimum voltage level. This must be set by the user.
Minimum Brightness–This is an integer value ranging from 0 to 9 that represents the
lowest backlight setting when the minimum brightness sensor voltage is present. This
must be set by the user.
Press BACK to save the settings and return to the LOCAL DISPLAY SETUP Menu or press EXIT to
return to the Main Menu.
Top Bar Setup
The top bar is the strip across the top of the screen. It displays textual information such as the
clock and autopilot status. Future software updates will use this space for information such as
radio status.
Enter the Top Bar Setup Page to configure the top bar (SETUP MENU > LOCAL DISPLAY SETUP >
TOP BAR SETUP).
Aircraft Information
Use the Aircraft Information Page (SETUP MENU > SYSTEM SETUP > AIRCRAFT INFORMATION)
to record important information about your aircraft.
The tail number must be present for SkyView network configuration and operation.
If you have more than one display in your SkyView system, the tail number only
needs to be set on the display that you initially perform the Network Configuration
on. At network configuration time, all other displays that are set to the default tail
number of DYNON will automatically have their settings and tail number
synchronized with the display the configuration is performed from. After
configuration, all displays’ tail numbers and settings will be synchronized, and
further setup tasks can be performed from any display.
