SV-XPNDR-262 Specifications
Specification
Characteristics
Compliance
ETSO 2C112b Class 2 Level 2els, ETSO
C166a Class B0, TSO C112c Class 2
Level 2els, TSO C166a Class B0
FCC Identification
VZI00675
Applicable documents
EUROCAE ED-73B, EUROCAE DO-
160F/ED-14F (RTCA DO-160F), RTCA
DO-181D, RTCA DO-260A change 2
Software
ED-12B (RTCA DO-178B) Level B
Hardware
DO-254 Level C
Power Requirements
11 – 33 Volts DC. Typical 5 Watts @
14Volts.
Altitude
35,000 feet
Humidity
95% @ +50°C for 6 hours; 85% @
+38°C for 16 hours.
Tested to Category A in DO-160F
Operating
Temperature
-20°C to +70°C
Transmitter Frequency
1090MHz ± 1MHz
Transmitter Power
125 Watts nominal; 71 Watts
minimum at antenna after allowing for
0.5dB connector losses and 1.5dB
cable losses.
Transmitter
Modulation
6M75 V1D
Receiver Frequency
1030 MHz
Receiver Sensitivity
-74Dbm ± 3Db
Physical Specifications (in the mounting tray)
Height
48mm (1.9”)
Width
66mm (2.5”)
Length
160mm (6.3”)
Weight
0.77lbs. (350 g)
Table 51 - SV-XPNDR-262 Specifications
