16. Appendix B: Specifications
SkyView Equipment Weights
SkyView Equipment Description
Weight
SV-D1000 with mounting screws
3 lb 0.7 oz (1.38 kg)
SV-D700 with mounting screws
2 lb 6.1 oz (1.08 kg)
SV-ADAHRS-20X
8.2 oz (0.23 kg)
SV-EMS-220
9.6 oz (0.27 kg)
SV-GPS-250
6.7 oz (0.19 kg)
SV-BAT-320
13.1 oz (0.37 kg)
SV-XPNDR-26X
14.4 oz (0.4kg)
SV-ARINC-429
6.0 oz (0.17kg)
SV32
2.0 lb. (0.91 kg)
SV42
3.0 lb.(1.36 kg)
SV52
4.0 lb.(1.81 kg)
SV-OAT-340
1.5 oz (0.04 kg)
SV-HARNESS-D37
7.5 oz (0.21 kg)
SV-NET-CHG
0.4 oz (0.01 kg)
SV-NET-SPL
3.2 oz (0.09 kg)
SV-NET-3CC
3.2 oz (0.09 kg)
SV-NET-6CC
4.6 oz (0.13 kg)
SV-NET-10CP
6.7 oz (0.19 kg)
SV-NET-15CP
8.8 oz (0.25 kg)
SV-NET-20CP
11.3 oz (0.32 kg)
SV-NET-30CP
15.2 oz (0.43 kg)
SV-NET-HUB
3.1 oz (0.09 kg)
Heated AOA/Pitot Probe and Heater Controller (100667-000)
11.3 oz (0.32 kg)
Unheated AOA/Pitot Probe (100141-000)
5.7 oz (0.16 kg)
Encoder Serial-to-Gray Code Converter (100362-000)
1.6 oz (0.05 kg)
EMS 37-pin Main Sensor Harness (100399-000)
13 oz. (0.37 kg)
EMS EGT/CHT 6-cylinder 25-pin Thermocouple Wire Harness
(100399-002)
11 oz (0.31 kg)
Manifold Pressure Sender (100434-000)
3.2 oz (0.09 kg)
Oil Pressure Sender (100411-002)
3.9 oz (0.11 kg)
Fuel/Coolant Pressure Sender (100411-000)
3.9 oz (0.11 kg)
Oil Temperature Sender (100409-000 and 100409-001)
2.1 oz (0.06 kg)
Single EGT Probe
1.4 oz (0.04 kg)*
Single CHT Probe
1.4 oz (0.04 kg)*
OAT Sender (100433-000)
3.2 oz (0.09 kg)
Fuel Flow Sender (100403-003)
3.9 oz (0.11 kg)
Carburetor Air Temperature Sender (100468-000)
2.1 oz (0.06 kg)
Ammeter Shunt (100412-000)
5.0 oz (0.14 kg)
Table 48–SkyView Equipment Weights
*This is for a single probe. Multiply by the number of probes to obtain total weight of probes.
