Basic SkyView Display Operation
3-12 SkyView System Installation Guide - Revision K
 Sensor Input Mapping...–Enter this wizard to map engine and environmental sensors to
SV-EMS-220 pins. Reference the EMS Sensor Input Mapping Section of this guide for
instructions on how to navigate and use this menu to map sensors.
 Screen Layout Editor–Enter this wizard to configure the placement and style of the
onscreen EMS gauges on EMS pages. Reference the EMS Screen Layout Editor Section of
this guide for instructions on how to use this wizard.
 Sensor Setup–Enter this menu to configure the graphical display properties of mapped
sensors. Reference the EMS Sensor Setting Section of this guide for more information
regarding sensor setup.
MAP Setup Menu
This menu contains links to the following wizards and menus:
 Terrain Warning Colors – Sets whether red and yellow terrain warning are provided on
the Map Page
 Red and Yellow Start – When the above setting is set to “YES”, these settings how far
above or below the aircraft’s current altitude the red and yellow colors persist.
Autopilot Setup Menu
This menu is not accessible until the autopilot servos in the system have been
successfully calibrated and tested. Reference the Autopilot Servo Calibration and
Test Procedures Section of this guide for more information.
This menu contains links to the following menus:
 Roll Axis–Enter this menu to configure autopilot roll axis parameters and options such as
torque, sensitivity, mode, maximum bank angle, and turn rate target.
 Pitch Axis–Enter this menu to configure autopilot pitch axis parameters and options
such as torque, sensitivity, default climb vertical speed, default descent vertical speed,
maximum airspeed, and minimum airspeed.
 Disengage Button–Enter this menu to configure disengage button options such as hold
to engage, enable broken line detect, and control wheel steering mode.
Transponder Setup Menu
This menu is not accessible unless a SV-XPNDR-26X is setup and configured.
Reference the SV-XPNDR-26X Installation, Configuration, and Testing Section of this
guide for more information.
This menu contains options that are used to set up and configure the SV-XPNDR-26X module.
Reference the SV-XPNDR-26X Installation, Configuration, and Testing Section of this guide for
more information.
