Major Component Physical Specifications
Table 4 contains physical specifications (dimensions are approximate—see respective
installation chapters for exact dimensions).
Physical Specifications
Dimensions
Weight
SV-D700
7.64" W x 5.51" H x 2.14" D
2.4 lb.
SV-D1000
10.32" W x 7.06" H x 2.14" D
3.0 lb.
SV-ADAHRS-200 and
SV-ADAHRS-201
4.71" W x 1.22" H x 2.61" D
8 oz.
SV-EMS-220
6.35" W x 1.09" H x 2.99" D
10 oz.
SV-GPS-250
2.19" W x 0.75" H x 3.44" D
7 oz.
SV-BAT-320
3.30" W x 2.10" H x 3.90" D
13 oz.
SV32
2.47” W x 4.20“ H x 3.98” D
2.0 lb.
SV42
2.47” W x 5.13“ H x 3.98” D
3.0 lb.
SV52
2.47” W x 6.05“ H x 3.98” D
4.0 lb.
SV-XPNDR-26X
1.9”W x 2.5”H x 6.3”D
12.3 oz.
SV-ARINC-429
4.75" W x 1.09" H x 2.61" D
6 oz.
Table 4–SkyView System Component Physical Specifications
Temperature Specifications
Table 5 contains environmental specifications.
Environmental Specifications
Storage Temperature
Operating Temperature
SV-D700
-40 °C to +70 °C
-30 °C to +60 °C
SV-D1000
-40 °C to +70 °C
-30 °C to +60 °C
SV-ADAHRS-200 and
SV-ADAHRS-201
-40 °C to +70 °C
-30 °C to +60 °C
SV-EMS-220
-40 °C to +70 °C
-30 °C to +60 °C
SV-GPS-250
-40 °C to +70 °C
-40 °C to +60 °C
SV-BAT-320
-20 °C to +60 °C
-20 °C to +60 °C
SV32
-30 °C to +75 °C
-30 °C to +60 °C
SV42
-30 °C to +75 °C
-30 °C to +60 °C
SV52
-30 °C to +75 °C
-30 °C to +60 °C
SV-XPNDR-26X
-55 °C to +85 °C
-20 °C to +70 °C
SV-ARINC-429
-40 °C to +70 °C
-30 °C to +60 °C
Table 5–SkyView System Component Environmental Specifications
