There are lights on the Ethernet port that are usually indicative of data transfer on
traditional Ethernet devices. In SkyView, they are used instead for display
troubleshooting purposes. See the Maintenance and Troubleshooting chapter for
more information about what these lights indicate.
Available Cables and Harnesses
The following table contains Dynon part numbers and descriptions for the components that will
typically be used to test and build a SkyView system. Note: network cables with the “CP” suffix
include the second connector—it just is not installed on the cable to facilitate easy routing
through tight areas of an aircraft.
Dynon Part Number
Description
SV-HARNESS-D37
SkyView Display Harness with Aircraft-Grade Tefzel
®
Wiring
SV-ETHERNET-3CC
SkyView Ethernet Cable - Low Smoke Zero Halogen (3 foot)
SV-NET-3CC
SkyView Network Cable with Aircraft-Grade Tefzel
®
Wiring
Both Ends with Connectors (3 foot)
SV-NET-6CC
SkyView Network Cable with Aircraft-Grade Tefzel
®
Wiring
Both Ends with Connectors (6 foot)
SV-NET-10CP
SkyView Network Cable with Aircraft-Grade Tefzel
®
Wiring
1 End with Connector, 1 End with Pins Only (10 foot)
SV-NET-15CP
SkyView Network Cable with Aircraft-Grade Tefzel
®
Wiring
1 End with Connector, 1 End with Pins Only (15 foot)
SV-NET-20CP
SkyView Network Cable with Aircraft-Grade Tefzel
®
Wiring
1 End with Connector, 1 End with Pins Only (20 foot)
SV-NET-25CP
SkyView Network Cable with Aircraft-Grade Tefzel
®
Wiring
1 End with Connector, 1 End with Pins Only (25 foot)
SV-NET-30CP
SkyView Network Cable with Aircraft-Grade Tefzel
®
Wiring
1 End with Connector, 1 End with Pins Only (30 foot)
SV-NET-SPL
SkyView Network Splitter with Aircraft-Grade Tefzel
®
Wiring
(1 foot)
SV-NET-SERVO
SkyView Network Cabling Kit for Autopilot Servos
(includes 20 feet of wires, connectors, connector shells, crimp contacts,
insertion tool, heat shrink, and zip ties). One SV-NET-SERVO is used for
each servo in most installations.
SV-NET-TEST
SkyView Network Test Cable–Not Aircraft-Grade
(10 foot)
SV-NET-HUB
SkyView Network Hub (5 SkyView Network connections)
Table 6–SkyView System Connection Hardware
Example SkyView Systems
SkyView systems are easily scalable and can accommodate a wide variety of components
ranging from a single display with one module to multiple displays with multiple modules. The
