SkyView Network Connection Pin-Out
SkyView Network
Male D9 Pin
SkyView Network
Cable Wire Color
Description
1
Green
SkyView Network Data 1 A
2
Black
SkyView Network Ground 1
3
White with Black
Stripe
SkyView Network Ground 2
4
White with Blue
Stripe
SkyView Network Data 2 B
5
Orange
SkyView EMS Auxiliary Voltage
6
Blue
SkyView Network Data 1 B
7
Red
SkyView Network Power 1
8
White with Green
stripe
SkyView Network Data 2 A
9
White with Red
stripe
SkyView Network Power 2
Table 56–SkyView Network Male D9 Pin-out and Wire Harness Colors
