Dynon Avionics SkyView - Tools and Equipment Required; Exhaust Gas Temperature (EGT) Probes

SV-EMS-220 Installation and Configuration
7-26 SkyView System Installation Guide - Revision K
Tools and Equipment Required
The following list contains commonly used tools and equipment, however some of the tools or
equipment listed below may not apply to your installation.
 Wire strippers
 22 AWG wire
 D-sub pin crimper
 Faston/ring terminal crimp tool
o Available from www.bandcspecialty.com – (316) 283-8000 – part number RCT-1
 Weather Pack crimp tool (common slip joint pliers will also work)
o Available from www.whiteproducts.com/tools.shtml
 #2 Phillips screwdriver
 Flathead screwdriver
 ¼” ID tubes, any necessary adapters, and clamps for routing manifold pressure to the
sensor.
 Drill and 1/8” bit
Exhaust Gas Temperature (EGT) Probes
Correct placement of EGT probes on the exhaust manifold is critical to obtaining accurate
readings. Placement differs between engine types and even specific models.
Consult the specific engine’s manual for proper EGT locations.
Rotax Engines
For Rotax 912 engines, only two of the four cylinders are typically monitored for EGT. Unlike the
CHT probes which are mounted on diagonal cylinders, the EGT probes should be mounted on
the two rear cylinders’ exhaust manifolds. It is critical that the EGT probes be mounted to
parallel cylinders’ exhaust manifolds for proper temperature comparison.
All Engines
Once you have determined the appropriate EGT locations for your engine, drill 1/8” diameter
holes at the specified positions in the exhaust manifold. Usually, this spot is 2 to 8 inches from
the cylinder. This spot should be on a straight portion of the exhaust manifold, as this provides
a better fit for the hose clamps. For best results, mount all probes the same distance from each
cylinder.
 Make sure the hole is placed to ensure that the probe does not interfere with the cowl
or spark plug. Also, when making holes, keep in mind that the probe could inhibit the
ability to perform routine maintenance if placed incorrectly.
 Place probe in exhaust manifold, and secure it by tightening the clamp with a flathead
screwdriver. Make sure the clamp is tight and provides a secure fit, but do not over-
tighten such that visible stress is put on the pipe.
