SV-ARINC-429 Installation and Configuration
SkyView System Installation Guide - Revision K 12-9
SV-ARINC-429 Related Settings
Go to the ARINC-429 SETUP under SETUP MENU > SYSTEM SETUP > ARINC-429.
SkyView supports up to two SV-ARINC-429 modules, but since most aircraft will only have one
installed, the “MODULE 2” section is normally disabled. If your aircraft does actually have two
SV-ARINC-429 modules, note that the serial numbers of each module are provided so you can
determine which module is which.
For each module, Set INPUT1 to the type of device connected to the SV-ARINC-429’s ARINC-429
RX 1 A and B inputs, any of GPS X or NAV X. The numerical designation of the device determines
what it will be called on the HSI. Note that any GPS/NAV slots that are highlighted in red are
already being used for other devices. Also note that though POS X is a possible setting, it should
generally not be used for ARINC devices.
Next set the INPUT SPEED parameter (HIGH or LOW), based on the output speed of your two
ARINC devices.
The SV-ARINC-429 has one ARINC output channel with 2 sets of pins on the connector for wiring
convenience. If one or both of your ARINC devices can accept commands, configure OUTPUT
SPEED appropriately.
If you have connected a device to ARINC-429 RX 2 A and B, repeat the above configuration for
the INPUT2 parameter; otherwise, leave it set to NONE.
Your ARINC-429 capable GPS and/or NAV will need to be configured appropriately as well.
Suggested settings for common devices can be found at http://wiki.dynonavionics.com.
