Appendix A: Maintenance and Troubleshooting
15-4 SkyView System Installation Guide - Revision K
6. Assuming the Autopilot was previously set up and working correctly, you only need to
recalibrate the servos by going to SETUP MENU > HARDWARE CALIBRATION > SERVO
CALIBRATION > CALIBRATION and following the on-screen instructions.
All other SkyView Network Components
1. Reinstall the SkyView Network component in the aircraft.
2. Reconnect all harnesses and connections as originally installed.
3. Power up the SkyView System.
4. From any display in the aircraft, reconfigure SkyView Network under SETUP MENU >
NETWORK SETUP > CONFIGURE…
5. No further action should be required.
Status Operation
SkyView displays give users access to vital operational information in the Display Hardware
Information Page (SETUP MENU > LOCAL DISPLAY SETUP > DISPLAY HARDWARE
INFORMATION). Note that the information in this menu may be useful during troubleshooting.
The information here cannot be edited on this screen; however, some parameters are editable
by the user on other screens.
This menu contains the following information:
 Display serial number
 Firmware version
 Display input voltage
 Backup battery charge state
 Operational state of the internal battery management circuitry
 Operational state of the internal voltage rails
 Screen brightness level
 Local light sensor output
 External light sensor output
 Brightness level output
 Contact input status
 Serial port status and current baud rate
 Button and joystick states
 Operational hours
Display Serial Number
The serial number of the display is noted here as SERIAL NUMBER: XXXXXX.
Display Firmware Version
The firmware version of the display is noted here as FIRMWARE VERSION: X.X.XX.XXX.
